Troubleshooting A Flooded Boat Engine: What To Do?

If your boat engine is flooded, it has too much fuel in the cylinder, which can make it difficult or impossible to start. This can be caused by improper use of the choke, incorrect use of the priming pump, or low cylinder compression. However, boat engines can also be flooded with water, which can occur if the engine is installed incorrectly or if an anti-siphon valve malfunctions. If your boat engine is flooded, it's important to identify and fix the issue to prevent further damage and ensure the safety of those on board.

How to identify a flooded boat engine

A flooded boat engine is a common cause of boat breakdowns, especially in cold weather when the engine needs more fuel to run smoothly. If your boat won't start, this could be the issue.

• A strong smell of gasoline, particularly around the exhaust. When an engine is operating normally, you shouldn't be able to smell any gasoline on board. However, with a flooded engine, the fuel comes out too fast and isn't burned, so it builds up inside the combustion cylinder.
• Wet spark plugs. If the engine becomes severely flooded, it may result in fouled spark plugs. This is when the spark plug ends get wet due to excess gasoline in the combustion cylinders. When a spark plug is wet, the electrical energy that should fire during starting is conducted away instead of igniting the fuel.
• The boat doesn't restart for the second time or won't start at all. Sometimes, a boat will send extra fuel to the engine to help it start. If the boat isn't allowed to run long enough to burn this extra fuel, it will remain in the engine, and the fuel mixture will be too rich when you try to restart.
• The engine sounds different while cranking it up.

If you notice these signs, it's important to address the issue promptly to prevent further complications.

What to do if your boat engine is flooded

A flooded boat engine is a common cause of boat breakdowns, especially in colder weather. If your boat engine is flooded with water, or there is too much gasoline in the cylinder, you will need to take action to prevent damage to the engine.

Symptoms of a flooded boat engine

Firstly, you need to be able to identify the problem. A flooded boat engine will often have symptoms including a strong smell of gasoline, wet spark plugs, and will not restart. Sometimes, the engine will sound different when cranking. These symptoms will vary depending on the severity of the flooding.

What to do

If your engine has flooded with water, you should not operate it again until you have identified and fixed the source of the problem. If seawater has entered the cylinders, you must act quickly to prevent irreversible damage.

If the engine is flooded with gasoline, open the throttle and wait a few seconds to allow air into the cylinder to compensate for the excess fuel. If the spark plugs are very wet, dry them first.

If the engine is flooded with water, the first step is to open or turn off the start battery switch, and then turn off the fuel supply. Put on safety glasses and remove the injectors or glow plugs. Cover the exposed holes with rags and then turn over the engine manually. If the engine turns freely, crank the engine for 5-10 seconds, then reinstall the injectors or glow plugs.

The next step is to drain the oil and replace it with fresh oil and a new filter. Remove the valve-cover oil-fill cap to allow water vapour to escape. Start the engine and let it run for 5 minutes, then repeat the oil change. Run the engine under moderate load, aiming to achieve an oil temperature of 200 degrees Fahrenheit if possible. Finally, carry out a third oil change and check the oil regularly for any signs of moisture.

If the engine has been flooded for over 24 hours, corrosion may have already set in. In this case, you will need to remove the valve cover and inspect for damage. Pour kerosene, light motor oil, or automatic transmission fluid over the valve train and tap each rocker arm with a light plastic-head hammer, checking for free movement. If the valves and rocker arms do not move freely, there may be damage to the valves, valve train, and piston, and you may need to remove the cylinder head.

Common causes of a flooded boat engine

A flooded boat engine is a common cause of boat breakdowns, especially in cold weather. It occurs when there is too much fuel in the cylinder, which can make it difficult or even impossible to start the engine.

Improper Use of Choke

Located in the neck of the carburettor, the choke is a small valve designed to reduce the amount of air/oxygen added to the fuel. If the choke is not disengaged immediately after starting the engine, too much fuel is pumped into the cylinders, resulting in flooding.

Incorrect Use of Priming Pump

The priming bulb is a small rubber button that pumps fuel into the motor when pressed. If this button is pressed too many times, it will flood the cylinders with fuel, rendering the engine unable to start.

Low Cylinder Compression

Low cylinder compression can cause a build-up of fuel and lead to engine flooding. This can be tested with a standard compression gauge, and the only fix is to replace the head gasket.

Non-Compliant Exhaust Systems

Non-compliant exhaust systems can allow water intrusion into the cylinders, which is a common issue for engines located at or below the waterline. This can occur if the engine is not installed according to the manufacturer's instructions, allowing a siphon to develop and fill the exhaust.

Anti-Siphon Valve Malfunction

An anti-siphon valve malfunction is another potential cause of seawater flooding in boat engines. This can allow seawater to enter the exhaust system and eventually flow back into the engine through an open exhaust valve.

Excessive Cranking

Excessively cranking the engine while bleeding the fuel system can also lead to seawater flooding. Each revolution of the raw-water pump moves a small amount of seawater into the exhaust system, which can eventually overflow back into the engine.

It is important to identify and address the cause of a flooded boat engine to prevent further issues and ensure the safe operation of the vessel.

How to prevent a flooded boat engine

A flooded boat engine is a common cause of boat breakdowns, especially in colder weather when the engine needs more fuel to run smoothly. It can also happen in very hot weather. Here are some tips on how to prevent a flooded boat engine:

Regularly Inspect the Compression System

Regularly inspecting the compression system can help prevent the boat engine from flooding. This includes checking the spark plugs, cylinder compression system, and choke valve. Make sure the spark plugs are in good condition and can ignite the air-fuel mixture properly. A faulty cylinder compression system can increase the fuel ratio inside the cylinder, leading to flooding.

Avoid Leaving the Choke Open for Long Periods

Leaving the choke open for extended periods can cause the boat engine to flood. The choke valve/cable restricts airflow in the carburetor, increasing fuel flow. While this can be helpful when the engine is stuttering, leaving it open for too long will pump too much fuel into the cylinders. Only use the choke during the first start sequence of the day or if the engine is having trouble starting.

Maintain the Fuel Injection System

A faulty fuel injection system can cause engine flooding. Fuel injectors deliver fuel under high pressure into the combustion chamber. If they are faulty, stick open, or there is high fuel pressure, the engine may flood. Regular maintenance and checks of the fuel injection system can help prevent this issue.

Keep the Carburetor in Good Condition

The carburetor mixes air and fuel to produce the proper mixture for the engine. If it is faulty, it can cause a very rich mixture and lead to a flooded engine. Regularly inspect and maintain the carburetor, including the needle valves, to ensure it is functioning correctly.

Be Mindful of Fuel Ratios

A flooded boat engine is when there is too much gasoline inside the combustion cylinder and not enough oxygen to burn it all. This can be caused by various issues, as mentioned above. It is important to be mindful of fuel ratios and not overuse the choke valve, which can increase the fuel ratio and lead to flooding.

What to do if your boat engine is submerged in water

If your boat engine is submerged in water, the first thing to do is not to operate it until you have identified and fixed the source of the problem. If the engine has been submerged for more than 24 hours, corrosion may have already set in, so act as quickly as possible.

Firstly, open or turn off the start battery switch, and turn off the fuel supply. Put on some safety glasses, then remove the injectors or glow plugs and cover the exposed holes with rags. You can then turn over the engine manually, a task often called "barring", by engaging a socket wrench with the alternator pulley. If you feel any resistance, stop, as a valve may be seized. If the engine turns freely, you can then crank the engine using the starter for 5-10 seconds, then reinstall the injectors or glow plugs.

Next, drain the oil and replace it and the filter. Remove the valve-cover oil-fill cap to let water vapour escape more easily. Start the engine and let it run for about five minutes. Then, drain and replace the oil and filter again. The oil may appear milky if water has leaked into the crankcase. Once this is done, start the engine and let it idle with no load for five minutes. After two no-load runs and oil changes, carry out a final oil change, and run the engine under a moderate load, with the valve-cover cap in place, ideally achieving an oil temperature of 200 degrees Fahrenheit.

If water has entered the cylinders, remove the injectors and turn them over by hand. If the engine has been flooded for more than 24 hours, repeat the first four steps, then remove the valve cover and inspect for visible damage to the valve train. Pour a generous amount of kerosene, light motor oil, or automatic transmission fluid over the valve train, and tap each rocker arm with a light plastic-head hammer, watching to see if the valves and rocker arms move freely. If they do not, there may be valve, valve train, and piston damage, and you may need to remove the cylinder head. If all valves and rockers move freely, and the engine turns freely when barred over, disable the run function, turn on the battery switch, and spray fogging oil into the air intake while cranking the engine for 30 seconds.
