The Magic Of Bottled Boats: A Step-By-Step Guide

Putting a boat in a glass bottle is an old form of maritime art. The oldest surviving ships in bottles were crafted by Giovanni Biondo at the end of the 18th century. The ship model in a bottle is a traditional and iconic type of impossible bottle, where an object placed inside a bottle appears too large to fit through its mouth. There are two ways to place a model ship inside a bottle: the simpler way is to rig the masts of the ship and raise them when the ship is inside the bottle; alternatively, with specialised long-handled tools, it is possible to build the entire ship inside the bottle. This text will explain the former method.

Choose a bottle with the right shape for your boat

The shape of the bottle you choose will determine the type of boat you should build. For instance, a tall, narrow bottle is best suited for a tall ship. A big square-rigged clipper would not fit through the neck of a bottle like this, but a topsail schooner would fill the empty space inside the bottle nicely.

If you want to build a ship with a wide hull, you will need to choose a bottle with a wide opening. The hull of the ship must still be able to fit through the bottle's opening.

Bottles with minor distortions and soft tints are often chosen to hide the small details of the ship, such as hinges on the masts.

Construct the basic hull

Constructing a basic hull for your ship in a bottle is a challenging but rewarding task. Here is a step-by-step guide to help you get started:

Step 1: Gather Materials and Tools

You will need blank pieces of wood, a pen or pencil for drawing, a drill, toothpicks, sandpaper, and a belt sander or Dremel tool for sanding. You may also want to use a piece of string or thread to help shape the hull.

Step 2: Draw and Drill

Begin by drawing the outline of your desired hull shape onto the wood. Drill holes through the wood that will form the upper and lower parts of the hull. Insert toothpicks into these holes to keep the wood pieces aligned during the construction process.

Step 3: Sanding

Use a combination of a belt sander, Dremel tool, and sandpaper to shape the hull. Start with the belt sander for the rough shape, then move to the Dremel tool for more precise shaping, and finally, use sandpaper to smooth out any remaining rough edges. Remember to frequently compare the hull with the bottle to ensure it will fit through the opening.

Step 4: Refine the Hull Shape

To create a more detailed hull shape, you can use the sanding drum on the Dremel tool to shape the rear of the hull where it narrows down to the rudder area. Take your time and work in small increments to achieve the desired shape.

Step 5: Smooth and Finish

Once you are satisfied with the overall shape, use sandpaper to smooth out any remaining imperfections. You can fold the sandpaper to create a shape that matches the contours of the hull. This will help you achieve a smooth and polished finish.

Step 6: Test Fit

Before proceeding to the next steps, it is important to test the fit of the hull inside the bottle. Make sure the hull can easily pass through the bottle's opening and that it sits securely inside. You may need to make minor adjustments to the hull shape or sand it down further to ensure a proper fit.

Remember, the key to constructing the basic hull is patience and precision. Take your time with each step and make adjustments as needed to ensure a well-crafted hull that forms the foundation for your ship in a bottle.

Add the keel and rudder

Now that you have the basic hull ready, it's time to add the keel and rudder, which will give your boat its stability and manoeuvrability.

For this step, you will need to purchase some very thin pieces of wood from a craft store. Look for pieces that are 1/16 x 1/16 inch in thickness; these will be used for both the keel and the rail on the top of the deck.

Take one of the thin strips of wood and attach it to the bottom of the hull to form the keel. You can use glue or any other strong adhesive to secure it in place. Make sure the keel is straight and aligned with the centre of the hull, as this will be essential for the boat's stability.

Next, take another strip of the same size and attach it to the top of the deck to create the rail. This will add a nice finishing touch to your boat and give it a more authentic look.

With the keel and rudder in place, your boat is really starting to take shape. In the next step, you will add some colour by painting the hull.

If you're happy with how the keel and rudder look, you can move on to the next step: painting the hull. However, if you want to add any additional details to the keel and rudder, such as carvings or other decorations, now is the time to do so. Take your time and be as creative as you like!

Paint the hull

Now it's time to paint the hull. You might find it easier to paint the pieces separately before gluing them together, rather than trying to paint a single piece of wood once the hull is finished. Apply a quick coat of paint to the various pieces. Once the paint is dry, glue the two top pieces and the two bottom pieces together to form the upper and lower halves of the hull.

You can use a quick coat of paint to cover the various pieces of the hull. This is often easier than trying to paint several colours onto a single piece of wood once the hull is finished. You can also add additional details to the hull and mast by dipping the tip of a toothpick into paint and dabbing it on.

When painting the hull, consider the colours and designs of real-life boats and ships. You can use different shades of blue to create a gradient effect, giving the impression of the hull being underwater. Alternatively, you could use a darker colour as a base and dry brush a lighter colour on top to create a weathered look. You can also add details such as stripes, flags, or other designs to the hull to make it more visually appealing.

If you want to add windows or portholes to your boat, you can paint those on as well. Use a small, detailed brush to carefully paint the windows, or you could use a toothpick to apply the paint. Allow the paint to dry completely before moving on to the next step.

Remember to work in a well-ventilated area when painting and follow all safety instructions on the paint container.

Build the mast and attach sails

Constructing the mast and booms requires careful planning, as you are working with limited space inside the bottle. The masts, spars, and sails are typically made from toothpicks, which may need to be sanded down to achieve the desired width. It is important to keep in mind that the masts will need to lie flat against the deck when inserting the ship into the bottle, so they should be designed with hinges or other mechanisms to allow for this movement.

The bowsprit, which is the forward-most spar on a ship, is usually made in two parts. The bottom stick is inserted into a hole drilled into the hull, while the top stick is glued to it. Two lengths of thread are then wrapped around them and secured with glue. The thread acts as a hinge and will be used to attach the sails later.

Similarly, the main mast can be made in two parts, with a hinge in the middle created by looping a small piece of wire through a tiny hole drilled at the bottom of the mast. This allows the mast to bend and lie flat against the deck when needed. The booms, or horizontal spars, can be attached to the mast using thread, which will also serve as a hinge.

Once the masts, spars, and booms are constructed, they can be attached to the hull of the ship using strings and hinges. It is important to ensure that the hull still fits through the bottle opening, even with the masts and spars attached. Bottles with minor distortions and soft tints can help hide small details like hinges on the masts.

After the rigging is complete, you can move on to creating the sails. Start by soaking a piece of typing paper in coffee to give it an aged look, then let it dry overnight. Draw light parallel lines about a quarter-inch apart on the paper, then cut it to size to create a pattern for the sails. Cut the coffee-stained paper to size, and add additional lines to create borders.

Finally, attach the sails to the masts and booms, being careful to only glue down one edge of each sail. This will allow other rigging parts to fold away from it when necessary. With your sails in place, you are now ready to insert the ship into the bottle and raise the masts using the strings attached to them.
