Understanding Boat Thermostat: Open Or Closed?

Knowing when your boat's thermostat is open is important for winterizing your boat. One way to check is to run the engine until the temperature gauge reads 160, at which point the thermostat should be open and you can switch to antifreeze. You can also feel the hoses leading to the thermostat housing – if the inlet hose is cool and the outlet hose is warm, the thermostat is open. Another method is to get a pot of water and heat it to a temperature that should activate the thermostat and observe the result.

The thermostat opens at around 160 degrees Fahrenheit

The thermostat on a boat opens at around 160 degrees Fahrenheit. This is important to know when winterizing your boat, as you should switch to antifreeze once the engine has reached this temperature. Running the engine until it gets to 160 degrees Fahrenheit ensures that the thermostat is open and that antifreeze will reach all the important parts of the engine.

There are a few ways to tell if your boat's thermostat is open. One way is to feel the hoses leading to and from the thermostat housing. If the inlet hose (coming from the pump) is cool and the outlet hose is warm, it means the thermostat is open and engine-heated water is flowing out of the housing. You can also observe the temperature gauge – if the temperature climbs to around 160 degrees Fahrenheit and then starts to drop, it means the thermostat is open.

It's important to note that the thermostat in a boat engine is not a strict open/shut situation. It opens and closes as necessary to maintain the proper temperature, allowing water to constantly circulate in the block whether the thermostat is open or closed.

If you want to test your thermostat, you can place it in boiling water. It should open in the water and close when removed. If it fails this test, it needs to be replaced, along with the gasket. A properly functioning thermostat is important as it allows the engine to operate at its designed temperature, preventing condensation and corrosion, and promoting complete combustion.

The thermostat will open when the engine is up to temperature

The thermostat in a boat engine will open when the engine is up to temperature. This is usually around 160 degrees Fahrenheit, but it can vary depending on the make and model of the engine. To know when the thermostat is open, you can check the temperature gauge; once the needle reaches the operating temperature, the thermostat should be open. If your boat doesn't have a temperature gauge, you can feel the upper radiator hose; when the thermostat is open, the hose will become very warm very quickly. You can also check the radiator; when the thermostat is open, you may see radiator fluid being circulated in the end tank of the radiator.

If you want to be absolutely sure that the thermostat is open, you can try one of the following methods:

• If your boat has a separate pressure tank with a clear or semi-clear radiator cap, you can watch for the coolant to start circulating through the tank when the thermostat opens.
• You can use an OBDII reader to monitor the temperature of the coolant. When the thermostat opens, the coolant temperature will start to drop as the engine coolant mixes with the colder coolant from the radiator.
• You can feel the hoses leading to and from the thermostat housing. If the inlet hose (coming from the pump) is cool and the outlet hose is warm, it means the thermostat is open and engine-heated water is flowing out of the housing.

It's important to note that the thermostat will be in various states of "open" after the engine is up to temperature, meaning it will always be partially open to some degree. Additionally, if you're winterizing your boat, it's crucial to ensure that the thermostat is open before running antifreeze through the engine to avoid damaging the block.

The thermostat may be stuck open if the engine is not getting warm

A boat's thermostat is a crucial part of its engine's cooling system. It opens and closes to regulate coolant flow and manage the engine's temperature. If the thermostat gets stuck open, it'll continuously circulate coolant even when it's not needed, leading to engine overcooling. This is often indicated by a blue low-temperature indicator on the instrument panel.

• Engine Overcooling: The engine will be overcooled as the coolant circulates even when it's not required. This will cause the engine to operate below its optimal temperature range, affecting its performance and fuel efficiency.
• Low Temperature Indicator: The blue low-temperature indicator on your boat's instrument panel will stay on, indicating that the engine is still cold. This indicator will remain on even after driving for an extended period.
• Fuel Efficiency Impact: A stuck-open thermostat will result in lower fuel efficiency. The engine running below its optimal temperature will lead to increased fuel consumption over time.
• Excess Wear on Components: The boat's engine and its components are designed to function within an optimal temperature range. When the thermostat is stuck open, the engine's internal components experience excess wear due to operating at lower temperatures, potentially leading to more expensive repairs in the long run.
• Heater Not Working: If your boat has a built-in heater, it may not work properly when the thermostat is stuck open. The heater relies on heat from the engine, which will not be available due to continuous coolant circulation.

To determine if your boat's thermostat is stuck open, you can perform the following checks:

• Temperature Gauge: If the temperature gauge in your boat always reads low, it could indicate a stuck-open thermostat. This results in the coolant not being retained in the engine long enough to warm up, leading to the issues mentioned above.
• Physical Inspection: Remove the thermostat housing and inspect the thermostat itself. If it appears stuck open or shows signs of corrosion or contamination, it may need replacement.
• Coolant Circulation: Check the coolant circulation by feeling the hoses leading to and from the thermostat housing. If the inlet hose (coming from the pump) is cool while the outlet hose is warm, it suggests that the thermostat is open and engine-heated water is flowing out.

The thermostat may be stuck closed if the engine is overheating

If your boat's engine is overheating, it could be that the thermostat is stuck closed. This is a common issue, and there are a few ways to identify and resolve the problem.

Firstly, you should check the temperature gauge. If the temperature is climbing and sitting around 160 degrees but never goes above or below this, it may indicate a stuck thermostat. You can also feel the thermostat housing and the hoses to see if one is cool and the other warm, which would suggest the thermostat is open and allowing coolant to flow. If both are hot, it may be stuck closed.

If you suspect the thermostat is stuck closed, you can try removing it and checking its functionality. You can do this by placing it in water and heating it to see at what temperature it opens. If it is old or faulty, it may need to be replaced.

Another way to check is to run the engine and monitor the temperature. If the temperature reaches 160 degrees and you see it start to drop, the thermostat is opening. If the temperature continues to climb, the thermostat may be stuck closed.

If your boat's engine is overheating, it is crucial to address the issue promptly to avoid further damage.

The thermostat can be tested by placing it in boiling water

Testing a boat thermostat with boiling water is a straightforward process. It involves placing the thermostat in boiling water and observing its behaviour to determine if it is functioning correctly. This test can be performed before installing the thermostat or as a way to diagnose issues with the boat's cooling system.

To begin the test, prepare a pot of boiling water. The water temperature can be measured with a thermometer for accuracy. Some people suggest that the water should reach 180 degrees Fahrenheit or the temperature indicated on the thermostat. However, others recommend boiling the water without specifying a target temperature.

Once the water is boiling, carefully place the boat thermostat in the water. It is important to take safety precautions to avoid burns. Observe the thermostat's behaviour. A functioning thermostat should open up as the water reaches the trigger temperature. The amount of opening can vary, but it should be noticeable. Some people have reported openings of around 1/8 inch, while others have observed openings of 1/2 inch or more.

It is important to note that the thermostat should not be tested above the boiling point of water, as this can lead to inaccurate results. Additionally, the test does not need to be performed at a specific altitude, as this does not affect a pressurised cooling system.

By performing this test, you can gain valuable information about the functionality of your boat's thermostat. If the thermostat fails to open at the appropriate temperature, it may need to be replaced. A faulty thermostat can cause the boat's engine to run too hot or too cold, leading to potential engine damage. Therefore, it is crucial to ensure the thermostat is functioning correctly before installing it or after experiencing cooling-related issues.
