Outboard Engines: Charging Boat Batteries

how does an outboard engine charge batteries on boat

Outboard motors can charge boat batteries, but the process depends on the type of outboard motor and the type of battery. A two-stroke engine charges batteries differently from a four-stroke engine. Most modern outboard motors with an electric start will have an alternator that charges the starting battery once the motor is running. However, the alternator will not charge deep cycle batteries, which power accessories like trolling motors, fish finders, and live well pumps. To charge deep cycle batteries, a separate charger is needed.

Characteristics Values
How does an outboard engine charge batteries on a boat? The alternator will take the responsibility to recharge the battery if the outboard is running. This will happen to compensate for the power used for starting the motor.
Types of outboard engine A two-stroke engine charges the batteries differently than a four-stroke engine.
Charging circuit Some boats contain charging circuits. They use an alternator to charge both the in-house and starting batteries. Johnson outboard charging is an example.
Charging method Using a solar panel for charging purposes is also an efficient method to charge the batteries. But the tradeoff of using solar panels is that it is quite expensive. Also, it is heavily reliant on the weather as well.
Horsepower The smaller the engine, the less an outboard alternator will charge it. Inversely, the more horsepower an outboard motor has, the more electricity it can generate.
Charging time It typically takes 4-6 hours.

shunwild

Outboard motors with electric start will charge the battery as it runs

Outboard motors with electric start will charge the battery as they run. This is similar to how a car charges its battery. However, it is important to note that this only applies to starting batteries, and not deep cycle batteries, which power additional accessories such as trolling motors, fish finders, and live well pumps.

The alternator in the outboard motor will charge the starting battery. The alternator will compensate for the power used to start the motor and any other power drawn by the boat. The alternator will not charge deep cycle batteries, so a separate charger is needed for those.

To determine if your outboard motor is charging your battery, you can use a voltmeter or a multimeter to check the voltage of the battery. When the motor is running, the voltmeter should read around 14.5V, indicating that the battery is being charged.

Additionally, the horsepower of the outboard motor will impact its ability to charge the battery. A higher horsepower outboard motor will have more charging power, while a smaller engine will result in less charging power from the alternator.

It is also worth noting that there are other ways to charge your boat's batteries, such as using a solar panel or a dedicated onboard battery charger. However, these methods may be more expensive or less reliable than using the outboard motor.

shunwild

A multimeter can be used to check if the outboard motor is charging the battery

To test the charging circuit, the multimeter can be connected across the outboard output without the batteries. The engine can then be started for a few seconds to check if any voltage is produced. If there is no voltage output, it suggests a problem with the charging system.

Another method is to use an amp meter, which requires breaking the line and inserting the amp meter. A digital multimeter can also be used, but an analogue meter is often preferred as it provides more stable readings due to the pulsed nature of the current.

For small outboards, it is important to note that they may not have a voltage regulator in the circuit. As a result, higher engine revs may be needed to achieve the desired voltage levels. Additionally, without a battery connected, the rectifier input may show high AC voltage at full revs, which can damage the rectifier.

By performing these tests and checking the voltage and current readings, you can determine if the outboard motor is effectively charging the battery.

shunwild

A stator outputs Alternating Current (AC) voltage and needs a rectifier regulator to change it into Direct Current (DC)

A stator is a static part of an alternator and does not move. It generates Alternating Current (AC) voltage by rotating a rotor inside its windings to produce a rotating magnetic field. However, most electrical devices require Direct Current (DC) to operate, which is why a rectifier regulator is needed to convert the AC output of the stator into DC.

The stator consists of two parts: a laminated core and outer insulated windings. The rotor, which is the moving part of the alternator, spins inside the stator's windings to produce AC. The stator is insulated because it contains high voltage. The rotor has magnets that rotate around the stator's plates, and together, they provide an electric charge.

The rectifier regulator converts the two-way flowing AC from the stator into one-way flowing DC. This process is called rectification, and it is necessary to power electrical devices and charge batteries. The rectifier regulator also regulates the voltage to maintain a safe level, typically between 13.5V and 14.7V, to prevent overvoltage and potential damage to electrical systems.

In the context of outboard engines and boats, the rectifier regulator plays a crucial role in charging batteries. Outboard motors, even those without an electric start, can often be equipped with a rectifier regulator to charge the boat's battery. This setup is similar to how a car's motor charges its battery. By utilising the motor's rotation to create electrical current, the rectifier regulator can convert it into regulated DC current suitable for charging the boat's battery.

shunwild

An alternator has the rectifier regulator built into it and can produce a lot more electricity compared to a stator

Outboard motors can charge a boat's battery in a similar way to how a car's motor charges its battery. The major components needed to achieve this are generator coils that create electrical current from the motor's rotation, and a regulator/rectifier to convert the coil output into regulated DC current suitable for charging the battery.

Some outboard motors may have lighting coils fitted to their flywheels. These produce alternating current (AC) and are designed to power the navigation lights of small open boats without batteries. The power from these systems is deliberately limited to prevent the light bulbs from blowing.

If you want to use a lighting coil to charge a battery, you can use a bridge rectifier and capacitor to make use of all the available current. This will provide more power, but the voltage may still not be high enough to effectively charge a battery. To solve this, you can either add a voltage regulator to keep the voltage down to a suitable level, or devise a simple circuit to convert the rectifier into a voltage doubler.

If your boat has an alternator, you can check if the charging circuit is working by checking the voltage at the battery with the motor off, and then again with the motor running. As the RPMs approach 2000, you should see an increase in voltage.

shunwild

An onboard battery charger can charge multiple batteries simultaneously

An onboard battery charger is a must-have for your boat, especially if you spend a lot of time on the water. These devices are made up of up to four separate battery chargers, known as "banks", housed together in a single casing that can be mounted on your boat. This allows you to charge multiple batteries simultaneously, instead of having to charge them one at a time.

Most modern outboard motors with electric start will have an alternator to charge your starting battery once the motor is running. However, the alternator will not charge your deep cycle batteries, which power additional accessories like trolling motors, fish finders, and live well pumps. To maintain your deep cycle batteries, you need a separate charger.

Having an onboard charger saves you the hassle of having to disconnect and reconnect your batteries each time you need to charge them. With an onboard charger, charging your deep cycle batteries is as simple as plugging in the charger once you reach land.

When selecting an onboard charger, it's important to do your research. Choose a charger that is fully waterproof, resistant to corrosion, and able to be mounted in damp or wet locations. Also, ensure that it's compatible with the chemistry and voltage of the batteries on your boat.

If you want to charge multiple batteries simultaneously, there are a few things to keep in mind. Firstly, ensure that the batteries are of the same age, brand, and capacity. This is important because you want them to have the same specific gravity in each cell. Secondly, keep the lead lengths between the charger and each battery as close to identical as possible to minimise voltage drop. Finally, consider adding current limiting or fuses to each connection for added protection.

Frequently asked questions

Yes, most outboard motors with electric start will charge the battery as the engine runs.

You can use a voltmeter to check the battery voltage before and after running the engine. If the voltage is higher after running the engine, it is charging the battery.

The type of battery depends on the size of the boat and the electronics setup. Smaller boats with fewer electronics can use a smaller battery, while larger boats with more electronics will need a larger battery.

An alternator produces direct current (DC) and has the rectifier regulator built-in. A stator produces alternating current (AC) and needs a separate rectifier regulator to convert the current to DC.

An onboard battery charger is recommended for boats with trolling motors. If you have a smaller boat with fewer electronics, you may not need a separate charger.
