The grounding/bonding system on a boat is one of the most misunderstood and overlooked systems, but it serves a critical role in a boat's electrical universe. The system is easy to identify as it's usually insulated copper wire with a green or green and yellow striped covering. One of the most important roles of the grounding system is to act as an alternative current path in the event of a short circuit at any of the AC appliances on board. It can also help dissipate a lightning strike.
| Characteristics | Values |
|---|---|
| Role | Acts as an alternate current path in the event of a short circuit at any of the AC appliances on board |
| Appearance | Insulated copper wire with a covering that's green or green with a yellow stripe |
| Other appearances | Uninsulated single-strand, heavy-gauge copper wire or flat copper strips run along the top of structural stringers |
| Function | Doesn't make anything electrical on the boat work |
| Function | Serves a critical role in the boat's electrical universe |
| Function | Helps dissipate a lightning strike |
| Wiring | Requires upgrading from a minimum of 8 AWG to a minimum of 6 AWG for secondary conductors connecting all of the various underwater metallic pieces on the boat |
| Wiring | Requires the addition of a minimum 4 AWG "down conductor" or an equivalent |
| Wiring | All of this should be connected either to a keel bolt or to a ground plate measuring at least 1 square foot |
| Wiring | The potential of all the various bits of connected metal will rise equally, thereby minimising the risk of a "side flash" on board your boat as the lightning strike dissipates |
| Wiring | All ground wires go to the negative terminal of the battery |
Explore related products
What You'll Learn
The role of a groundwire in the event of a short circuit
The grounding system on a boat is often overlooked and misunderstood. It is usually an insulated copper wire with a green or green and yellow striped covering. The system doesn't make anything electrical on the boat work, but it is critical when things go wrong.
In the event of a short circuit, the ground wire acts as an alternate current path. This ensures that the AC grounding conductor on the power supply or AC output side carries little to no fault current.
The ground wire can also help dissipate a lightning strike. Upgrading the wiring in the grounding system can minimise the risk of a 'side flash' on board as the lightning strike dissipates.
It is important to note that all ground wires should go to the negative terminal of the battery. Connecting the ground wire to the hull can cause problems.
